| Emal və fərdiləşdirmə | Bəli |
| Brend | Digər |
| Model | CWZ-102A |
| Növ | Rəqəmsal taxometr |
| Enerji təchizatı gərginliyi: | Təchizat gərginliyi: DC24V soil 20% (or AC220V) |
| İş mühiti: | İş mühiti: ambient temperature -20c- +60c, relative temperature ≤98% |
| Ölçmə diapazonu: | Ölçmə diapazonu: soil 30~scale 999 rpm |
CWZ-102A型艉轴转速方向测量装置，适用于船舶艉轴(中间轴)转速测量和
倒顺转检测，可作多路指示。本装置采用微电脑控制，全数字化测量，检测能力
强，可靠性好。采用双色大屏幕数码管显示，读数正确、直观、稳定，前进顺转
为绿色，后退倒转为红色，停车为橘黄。本装置为非接触磁感应测量，灵敏度高，
感应距离大，小磁钢感应测速，省去了笨重的测速齿盘，安装方便。输出接口可
并接5只数字式艉轴转速表。
CWZ-102A type stern shaft speed direction measuring device is suitable for ship stern shaft (intermediate shaft) speed measurement and reverse and reverse rotation detection, and can be used for multi-channel instructions. This device adopts microcomputer control, fully digital measurement, strong detection capability and good reliability. It adopts a two-color large-screen digital tube display, and the readings are accurate, intuitive and stable. The forward direction is green, the reverse direction is red, and the parking light is orange. This device is a non-contact magnetic induction measurement with high sensitivity, large sensing distance, small magnetic steel induction speed measurement, eliminating the need for a bulky speed measuring gear, and is easy to install. The output interface can be connected in parallel with 5 digital stern shaft tachometers.
