Vgate Icar Pro ELM327 OBD2 II Bluetooth 3.0 avtomobil diaqnostika cihazı

Vgate icar pro OBDII INTERFACE蓝牙3.0支持Android
编号：CTC097
产品描述
Vgate iCar OBD II适配器是由香港Vgate Technology Co Ltd开发的功能强大的汽车诊断工具。
它符合完整的OBD II / EOBD规范。多种无线连接模式*，用于连接智能手机或平板电脑。
它读取实时的汽车发动机数据，例如发动机转速，点火时间，油耗，水温，油耗。
它支持各种OBD II应用程序。
Vgate iCar蓝牙3.0 OBD II adpater是高质量的汽车扫描工具。
特征：
●清除检查引擎灯-这款iCar Pro代码阅读器将帮助您节省金钱并准确诊断检查引擎灯问题。很好用。
●简单易用-在过去的20年中，大多数汽车都配备了OBD2诊断端口，只需找到该端口并插入iCar Pro。
●合身而忘-因为它的微小尺寸和独特的省电功能可以保护您的电池，因此完全可以放心而忘记
●可与数百种应用程序协同工作-Vgate iCar Pro蓝牙低功耗设备可与 的OBD应用程序配合使用。请在产品说明中找到Android设备的下载说明。
●2年保修-作为标准，我们提供2年保修。如果您对设备有任何问题，只需将其寄回，我们将在下一个工作日发货。
功能：
●阅读非特定故障代码和制造商特定故障代码。快速ARM处理器，每秒最多可支持30个PID。
●读取和删除故障代码，关闭MIL（检查发动机灯）。查看冻结帧数据和I / M准备情况监视器。存钱！
●读取实时ECU传感器数据（发动机RPM，燃油系统状态，燃油压力，氧气传感器电压以及车辆上的许多可读参数）。准备进行排放测试。
......
购买前的提示：
为了使您的车辆兼容OBD II，必须具有16针DLC（数据链接）
破折号和车辆排放控制信息下的连接器）
标签必须注明该车辆符合OBD II。为确保您的车辆符合OBD-II，请在车辆上寻找贴纸
发动机舱内发动机罩下方清楚地标明“符合或符合OBD II标准”。
车辆范围：
适用于所有OBD2车辆（从1996年开始在美国使用）和EOBD车辆（汽油
欧洲的2001年汽车和2003/2004年的柴油汽车）
支持的OBD-II协议：
SAE J1850 PWM（41.6波特）
SAE J1850 VPW（10.4波特）
ISO9141-2（5波特init，10.4 Kbaud）
ISO14230-4 KWP（5波特init，10.4 Kbaud）
ISO14230-4 KWP（快速初始化，10.4 Kbaud）
ISO15765-4 CAN（11位ID，500 Kbaud）
ISO15765-4 CAN（29位ID，500 Kbaud）
ISO15765-4 CAN（11位ID，250 Kbaud）
ISO15765-4 CAN（29位ID，250 Kbaud）
SAE J1939 CAN（29位ID，250 * Kbaud）
USER1 CAN（11 *位ID，125 * Kbaud）
USER2 CAN（11 *位ID，50 * kbaud）
如何设置蓝牙配对：
BT3.0型号版本
主屏幕
进入设定页面
选择V-LINK默认密码为“ 1234”
设备已配对
运行扭矩应用
转到扭矩应用OBD II适配器设置
选择连接类型>蓝牙
选择蓝牙设备> V-LINK
完全退出扭矩应用
RunTorque应用
连接的
规范：
电源电压：11.5V—15V
供电电流：<200Ma
待机电流：<30Ma（TONWON Pro = <3Ma）
工作温度：-40℃--85℃
工作湿度：5％-95％RH（无露水）
包裹包括：
1个x Vgate iCar Pro蓝牙3.0 OBDII适配器
1个x用户手册

Vgate icar pro OBDII INTERFACE Bluetooth 3.0 support Android

ID NO.:CTC097

Product Description

Vgate iCar OBD II adapter is a powerful car diagnostic tool developed by HK Vgate Technology Co Ltd.
It is compliant with full OBD II/EOBD specifications. Various wireless connection modes* to connect your smartphone or pad.
It reads the real-time car engine data, such as engine speed, ignition time, fuel trim, water temperature, fuel consumption.
It support a variety of OBD II apps.

Vgate iCar Bluetooth 3.0 OBD II adpater is a high-quality automotive scanning tool.
Features:

● CLEAR CHECK ENGINE LIGHT - This iCar Pro code reader will help you save money and accurately diagnose check engine light problem. Very easy to use.
● EASY FITMENT - The majority of cars made in the past 2 decades are fitted with an OBD2 diagnostic port, simply find the port and plug the iCar Pro in.
● FIT AND FORGET - It really is possible to fit and forget beacuse it's micro size and unique power saving functionality that protects your battery
● WORKS WITH HUNDREDS OF APPS - The Vgate iCar Pro Bluetooth Low Energy device works with the most popular OBD apps. Please find download instruction for Android device in product description.
● 2 YEAR WARRANTY - We offer a 2 year warranty as standard. If you have any problem with the device simply send it back and we will despatch a brand new replacement the following working day.
Functions:

● Read both nonspecific and manufacturer specific trouble codes. Fast ARM processor allowing up to 30 PID's per second.
● Read and delete fault codes, Turn off MIL (check engine light). view freeze frame data & I/M readiness monitors. Save money!
● Read real-time ECU sensor data (Engine RPM. Fuel System status, Fuel Pressure. Oxygen sensor voltages and many readable parameters on your vehicle). Prepare for emission testing.
......
Tips before your purchase:
 For your vehicle to be OBD II compliant it must have a 16-pin DLC (Data Link
Connector) under the dash and the Vehicle Emission Control Information
Label must state that the vehicle is OBD II compliant. To be sure your vehicle complies with OBD-II, look for a sticker on the vehicle
under the hood in the engine compartment that clearly states “OBD II compliant or certified”.
Vehicle Coverage:
Works on all OBD2 Vehicles (1996 onwards in USA) and EOBD vehicles (Petrol
cars from 2001 and diesel cars from 2003/2004 in Europe)
OBD-II protocols supported:
SAE J1850 PWM(41.6 Kbaud)
SAE J1850 VPW(10.4 Kbaud)
ISO9141-2(5 baud init,10.4 Kbaud)
ISO14230-4 KWP(5 baud init,10.4 Kbaud)
ISO14230-4 KWP(fast init,10.4 Kbaud)
ISO15765-4 CAN(11bit ID,500 Kbaud)
ISO15765-4 CAN(29bit ID,500 Kbaud)
ISO15765-4 CAN(11bit ID,250 Kbaud)
ISO15765-4 CAN(29bit ID,250 Kbaud)
SAE J1939 CAN(29bit ID,250* Kbaud)
USER1 CAN(11*bit ID,125* Kbaud)
USER2 CAN(11*bit ID,50* kbaud)
How to setup Bluetooth pairing:
BT3.0 model version
Home screen
Go to setting page
Select V-LINK Default password is “1234”
Device paired
Run Torque app
Go to Torque app OBD II adapter setting
Choose connecion type>Bluetooth
Choose Bluetooth device>V-LINK
Exit Torque app completely
RunTorque app
Connected
Specification:
Supply Voltage: 11.5V—15V
Supply Current:  <200Ma
Standby Current: <30Ma  ( TONWON Pro   =<3Ma )
Operating Temperature: -40℃--85℃
Operating Humidity: 5%--95%RH Non-Dewfall
Package Includes:
1pc x  Vgate iCar Pro Bluetooth 3.0 OBDII adapter
1pc x User manual
